OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw

Zhengzhou The Right Time Import And Export Co., Ltd.
Contact Now
    Buy cheap OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw from wholesalers

    Buy cheap OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw from wholesalers
    • Buy cheap OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw from wholesalers

    OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw

    Ask Lasest Price
    Brand Name : ZDS
    Model Number : 330
    Price : USD33000/sets
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30sets/months
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw

    Computer panel saw


    Max.Cutting lenght
    2700MM
    3300MM
    3850MM
    Max.Cutting thickness
    100~120MM
    100~120MM
    120MM
    Positioning method
    Automatic
    Automatic
    Automatic
    Positioning accuracy
    ±0.02mm
    ±0.02mm
    ±0.02mm
    Cutting accuracy
    ±0.15mm
    ±0.15mm
    ±0.15mm
    Main saw motor power
    15kw
    15kw或18.5kw
    18.5kw
    Main saw blade diameter
    400~450mm
    400~450mm
    450mm
    Main shaft diameter
    60mm
    60mm
    60mm
    Main saw speed
    3800r/min
    3800r/min
    3800r/min
    Saw car servo motor power
    1.5kw
    1.5kw
    1.5kw
    Mechanical hand servo motor
    1.5kw
    1.5kw
    1.5kw
    Auxiliary saw motor power
    1.5kw
    1.5kw
    2.2kw
    Vice saw blade diameter
    180mm
    180mm
    180mm
    Sub shaft diameter
    30mm
    30mm
    30mm
    Secondary saw speed
    6100r/min
    6100r/min
    6100r/min
    Feeding speed
    0~80M/min
    0~80M/min
    0~80M/min
    Cutting speed
    0~80M/min
    0~80M/min
    0~80M/min
    Return speed
    0~120M/min
    0~120M/min
    0~150M/min
    Air pressure
    0.6-0.7MPA
    0.6-0.7MPA
    0.6-0.7MPA
    Machine tool dimension
    5200MM×5600MM
    5600MM×6000MM
    6600MM×7000MM
    Net weight
    About 5500KG
    About 5800KG
    About 6800KG
    Total power
    22kw
    22kw
    28kw

    OEM ODM MDF Board Computer Panel Saw 3300mm Cutting Length Computer Beam Saw

    It is suitable for cutting all kinds of plates, saving labor, improving efficiency and reducing safety accidents.

    FAQ
    Q1: How to make an order?
    A1:You can order online , Or Email us your details, and we will contact you immediately and help you proceed with the orders.
    Q2: Can you offer special discounts to the wholesaler or we make big quantity?
    A2:Yes, we will give you best support according to your quantity.
    Q3: What is your delivery time?
    A3:Normally, we can finish one order at about 25-30days, but the exact time depends on different styles and different quantities you order.
    Q4: Can you arrange the shipment by door to door?
    A4:We can offer door to door service both by sea and by air, which can save your time and money. Also, we have cooperated forwarder in some countries and can arrange the customs clearance for you.
    Q5: Do I have to assemble all items by myself or by my customer himself?
    A5:Our packing will be two different ways according to different products. Some are used the KD packing (for
    some little spare parts), and others need to be assembled, But it is so easy to assemble with the user manual or video teaching.
    Q6: What's your warranty?
    A6:We normally will provide one years warranties. If the product is caused by factory mistakes, We will
    give you replacement for the spare parts. If it was damaged during the shipping or other reasons, we will provide the best
    solutions for you.
    Q7:What payment do you accept?
    A7:Normally we can provide TT, LC, PAYPAL, ESCROW, WESTERN UNION ect. Any other ideas, please contact us for better support.
